Gravity Conveyor Roller Series GR-SB-1400
Steel Ball BearingUsed with gravity conveyor for medium weighted applications. It can be used in manufacturing plant, assembly line or food possessing line. Or any other suitable application as per requirement.
| General Technical specifications | |
|---|---|
| Model no. | GR-SB-1400 |
| Max. Load capacity | 1500N -5000N |
| Max conveyor speed | 0.8m/s |
| Material used for construction | MS, Aluminum, Stainless steel, MS with PVC sleeved |
| Shaft | Steel, Zinc –plated, MS, Stainless steel |
| Bearing | Sheet Metal Bering |
Manufactured with uncaged sheet metal bearing & hexagonal shaft, which makes the assembly & dismantling of the roller is very easy. No support bracket or slot on the stringer is required.
|
ROLLER SIZE GR-SB-1400 |
||||||
|
Tube Metal |
Tube/thickness {mm} |
Shaft{mm} |
Tube length{mm} |
Load Capcity{N} |
||
|
|
|
|
Min |
Max |
Min |
Mx |
|
|
25.4 x 2.5 |
8 |
100 |
1500 |
300N |
2500N |
|
MS, SS, MS + PVC |
31.75 x 2.5 |
12 |
||||
|
33.7 x 3.6 |
12 |
|||||
|
38.1 x 3.6 |
12 |
|||||
|
42.3 x 3.9 |
15 |
|||||
|
48.3 x 4.0 |
20 |
|||||
|
50.8 x 2.9 |
20 |
|||||
|
60.3 x 2.9 |
15 |
|||||
|
63.3 x 2.9 |
15 |
|||||
|
60.3 x 4.5 |
20 |
|||||
